Quectel EC200UCN 4G LTE Modem – 5V TTL, USB & JIO SIM Support
₹1,510.40 incl. GST (₹1,280.00 + GST)
The Quectel EC200U-CN 4G TTL Modem is a versatile cellular module supporting 4G LTE and 2G GSM/GPRS for IoT, remote monitoring, SMS, and telemetry. With 5V power, TTL UART, Micro USB, and SMA antenna connectivity, it is ideal for Arduino, ESP32, STM32, smart automation, and IoT projects.
Quectel EC200U-CN 4G TTL Modem
Product Description
The Quectel EC200U-CN 4G TTL Modem is a cellular communication module designed for IoT, remote monitoring, telemetry, automation, SMS gateways, and connected embedded projects. It supports 4G LTE-FDD, LTE-TDD, and 2G GSM/GPRS networks and is designed for easy integration with Arduino, ESP32, STM32, and other microcontrollers.
The module features both TTL UART and Micro USB interfaces, providing flexibility for development, testing, AT command configuration, and embedded communication.
Arduino & Microcontroller Ready
This version operates from a 5V supply and includes an onboard TTL level converter, allowing convenient connection to 5V microcontrollers such as Arduino Uno and Mega without requiring a separate level-shifting circuit.
It can be powered through the 5V input pin or Micro USB interface, making it convenient for both standalone testing and embedded projects.
4G Cellular Connectivity
The EC200U-CN supports LTE-FDD, LTE-TDD, and GSM/GPRS connectivity for applications requiring cellular data, SMS, and voice communication.
According to the supplied product information, the module is intended for use with major Indian networks including JIO and Airtel.
Dual Interface Design
TTL UART
The TTL serial interface allows direct communication with Arduino, ESP32, STM32, and other microcontrollers using supported AT commands.
Micro USB
The Micro USB interface can be used for PC connection, testing, configuration, and AT command communication.
Key Features
- Quectel EC200U-CN 4G LTE modem
- Supports LTE-FDD and LTE-TDD
- Supports 2G GSM/GPRS
- TTL UART interface
- Micro USB interface
- Onboard TTL level converter
- 5V power input
- Micro SIM card slot
- SMA antenna connector
- Power, network, and status indicators
- Supports TCP, UDP, PPP, MQTT, and HTTP
- Suitable for Arduino, ESP32, and STM32
- Standard model does not support GNSS/GPS
Technical Specifications
| Feature | Specification |
|---|---|
| Model | Quectel EC200U-CN |
| Network Type | 4G LTE-FDD / LTE-TDD + 2G GSM |
| Carrier Support | JIO, Airtel etc. |
| Input Voltage | 5V DC |
| Current Requirement | 500mA, with up to 2A peak recommended |
| Interface | TTL UART & Micro USB |
| Antenna Connector | SMA Female |
| SIM Slot | Micro SIM |
| GNSS/GPS | Not Supported – Standard Model |
Working Principle
The modem connects to a supported cellular network using a compatible SIM card and external antenna. A microcontroller or computer communicates with the modem through the UART or USB interface using AT commands.
It can then be used for cellular data communication, SMS transmission and reception, voice-related functions, and network-based IoT applications.
Communication & Protocol Support
The module supports common communication protocols and AT-command functions for applications involving:
- TCP communication
- UDP communication
- PPP connectivity
- MQTT
- HTTP
- SMS
- Cellular data communication
Typical Application Scenarios
SMS Gateway
Suitable for sending and receiving automated SMS messages using Arduino or another microcontroller.
Remote Telemetry
Can transmit sensor readings and device information to remote servers through a 4G cellular network.
Smart Vending Machines
Useful for remote monitoring, inventory communication, and cellular-based connectivity.
Home Automation
Can provide remote cellular communication for appliance control, alerts, and monitoring systems.
Applications
- 4G IoT projects
- Remote telemetry
- SMS gateways
- Cellular data logging
- Smart vending machines
- Home automation
- Remote monitoring
- Industrial IoT
- Arduino cellular projects
- ESP32 cellular projects
- STM32 communication systems
- Embedded GSM/LTE applications
View our complete Range of 4G Modems here.
Download the additional Resources here
Package Includes
- 1 × Quectel EC200U-CN 4G TTL Modem
Product Disclaimer
Product information may vary between manufacturers, suppliers, firmware versions, and production batches. Please verify the actual module specifications, supported bands, carrier compatibility, and interface details before use.
Product images are for illustrative purposes only and may differ from the actual product in colour, connector placement, component markings, or other visual details.
Important Note
SIM Card
A compatible Micro SIM card with an active cellular service is required for network connectivity.
Antenna
A suitable 4G antenna connected through the SMA connector is required for cellular operation.
Power Supply
The modem can require significant current during cellular transmission, with peak requirements potentially reaching approximately 2A according to the supplied information. Use a stable 5V power source capable of handling these current demands.
GPS / GNSS
This standard version does not support GNSS/GPS. A GNSS-enabled version should be used when satellite positioning is required.
