ESP32-CAM Camera Development Board OV2640 /OV3660 Camera Module

The ESP32-CAM is a high-performance, ultra-compact development board that combines the power of the ESP32 chip with a video camera module. Designed for the next generation of IoT applications, this board offers a complete solution for smart surveillance, wireless imaging, and AI recognition projects in a small DIP-packaged form factor.

Powerful & Efficient Core

At its heart lies a low-power dual-core 32-bit CPU capable of running up to 240MHz. With built-in 520KB SRAM and an external 4MB PSRAM, the ESP32-CAM handles image processing and streaming with ease, making it superior to standard ESP32 modules for video tasks.

Wireless & Storage Versatility

This module features integrated 802.11b/g/n Wi-Fi and Bluetooth BLE, ensuring robust wireless connectivity. It supports multiple networking modes (STA/AP/STA+AP) and features a specialized TF card slot for storing images and video locally, eliminating the need for constant cloud uplinks.

Key Features

• Dual-Core Power: Low-power 32-bit CPU, 240MHz frequency, 600 DMIPS computing power.

• High-Spec Memory: Integrated 520KB SRAM + 4MB external PSRAM for stable video streaming.

• Camera Versatility: Comes with either OV2640 or OV3660 camera module (subject to availability).

• Rich Interfaces: Supports UART, SPI, I2C, PWM, ADC, and DAC for versatile sensor connection.

• Easy Setup: Supports Smart Config / AirKiss one-click network distribution.

• Firmware Support: Capable of local serial upgrade and remote firmware upgrade (FOTA).



Technical Specifications

Typical Application Scenarios

• Home Automation: Smart video doorbells and pet monitoring systems.

• Wireless Surveillance: Remote CCTV cameras that stream over Wi-Fi.

• AI Vision: Face Detection and related Projects.

• IoT Edge: Remote sensors capturing visual data.

If you are looking for More capable camera for Face Recognition/AI vision related task please check

For Programming you can buy the base board here.

Package Includes

• 1 x ESP32-CAM Development Board

• 1 x Camera Module (OV2640 or OV3660 – Random)

  (Note: TF Card and USB-to-TTL programmer are usually sold separately)

Important Product Disclaimer

Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product images are shown for illustrative purposes only and may differ from the actual product.

Note

Stock Availability Note: Depending on current stock levels, you may receive either the OV2640 or the OV3660 camera module. Both modules are fully compatible with the board and offer excellent performance for IoT projects.
