DRV8825 Stepper Motor Driver Module With Heat Sink

The DRV8825 stepper motor driver carrier is a breakout board for TI?s

DRV8825 microstepping bipolar stepper motor driver.

The module has a pinout and interface that are nearly identical to those of our A4988 stepper motor driver carriers, so it can be used as a higher-performance drop-in replacement for those boards in many applications.

The DRV8825 features adjustable current limiting, overcurrent and

overtemperature protection, and six microstep resolutions (down to 1/32-step).

It operates from 8.2 ? 45 V and can deliver up to approximately 1.5 A per

phase without a heat sink or forced air flow (rated for up to 2.2 A per coil with sufficient additional cooling).

Features:

• Simple step and direction control interface
• Six different step resolutions: full-step, half-step, 1/4-step, 1/8-step, 1/16-step, and 1/32-step
• Can interface directly with 3.3 V and 5 V systems
• Over-temperature thermal shutdown, over-current shutdown, and under-voltage lockout
• Short-to-ground and shorted-load protection
• 4-layer, 2 oz copper PCB for improved heat dissipation
• Exposed solderable ground pad below the driver IC on the bottom of the PCB

Module size, pinout, and interface match those of our A4988 stepper motor driver carriers in most respects (see the bottom of this page for more
