Ai-Thinker VC-02-Kit Voice Recognition Development Board

Product Description

The Ai-Thinker VC-02-Kit is a development board designed specifically for the VC-02 offline speech recognition module. It shares the same hardware platform as the VC-01-Kit and integrates a CH340C USB-to-serial interface, enabling convenient debugging and firmware upgrades through a USB connection.

The development board includes status indicator lights for wake-up and operation states, allowing easy monitoring and control during development. The VC-02 module itself is built around the Unisound US516P6 voice processor, which combines a 32-bit RISC core, DSP instruction set, floating-point processing unit, and an FFT accelerator to deliver reliable and fast offline speech recognition.

Supporting up to 150 local offline voice commands, the VC-02-Kit enables voice interaction without requiring internet connectivity. This makes it suitable for smart home products, household appliances, toys, lighting systems, control panels, and other embedded voice-control applications.

Key Features

• Offline speech recognition development kit

• Supports up to 150 local voice commands

• Based on Unisound US516P6 voice chip

• 32-bit RISC CPU running at 240MHz

• DSP instruction set with floating-point unit

• Built-in FFT accelerator

• All GPIOs configurable as external interrupt and wake-up sources

• One full-duplex UART supporting up to 3 Mbps

• Supports I2C, DAC, PWM and multiple peripheral interfaces

• Built-in 242KB high-speed SRAM

• Built-in 2MB Flash memory

• Supports dual-channel DAC output

• USB connection via CH340C UART bridge

• Lightweight RTOS support

• Simple and user-friendly configuration tools

Typical Applications

• Smart home voice control systems

• Voice-controlled household appliances

• Lighting and switch control

• Toys and consumer electronics

• Embedded voice-interaction products

• DIY and prototyping projects

Package Includes

• 1 × Ai-Thinker VC-02-Kit Development Board with Speaker and Microphone Module
