Ultimate Pico RP2040 16MB Development Board – Powerful 128Mbit USB-C Board

The Ultimate Pico RP2040 16MB Development Board is a compact and powerful microcontroller board designed for embedded system projects, IoT applications, robotics, automation, electronics learning, prototyping, and advanced microcontroller development. It is based on the RP2040 chip, which features a dual-core ARM Cortex-M0+ processor running up to 133 MHz, making it suitable for both beginners and experienced developers.

This development board comes with 128Mbit onboard flash memory, which is equal to 16MB storage. The larger flash memory is useful for projects that require more space for firmware, MicroPython libraries, CircuitPython files, web assets, configuration files, images, audio samples, data logging, or larger embedded applications. Compared to standard RP2040 boards with lower flash capacity, this 16MB version gives developers more flexibility when building feature-rich projects.

The board includes a modern USB-C connector, which makes programming and powering the board simple and convenient. It supports popular development environments such as MicroPython, CircuitPython, Arduino IDE, and C/C++, giving users the freedom to choose the programming platform that best fits their project requirements. Whether you are learning microcontrollers or developing a working prototype, the Ultimate Pico RP2040 16MB Development Board offers a reliable platform for experimentation and product development.

This RP2040 board supports common hardware interfaces including SPI, I2C, UART, PWM, ADC, and PIO. These interfaces allow the board to connect with a wide range of sensors, OLED and TFT displays, motor drivers, relays, wireless communication modules, GPS modules, data storage modules, and other electronic components. The flexible GPIO support also makes it suitable for robotics, automation control, USB HID projects, sensor monitoring, and educational electronics.

The board includes 30 multifunction GPIO pins, allowing users to build complex circuits and connect multiple peripherals. With 264KB SRAM and 16MB flash storage, it can handle many practical embedded applications, from simple LED control projects to more advanced IoT and automation systems. The RP2040’s PIO feature also allows advanced users to create custom communication protocols and timing-sensitive applications.

Key Features

• RP2040 dual-core ARM Cortex-M0+ microcontroller
• Clock speed up to 133 MHz
• 128Mbit onboard flash memory, equal to 16MB
• 264KB SRAM
• USB-C connector for programming and power
• 30 multifunction GPIO pins
• Supports SPI, I2C, UART, PWM, ADC, and PIO
• Compatible with MicroPython, CircuitPython, Arduino IDE, and C/C++
• Suitable for IoT, robotics, automation, embedded systems, and learning
• Compact board for prototyping and product development

Technical Specifications

Typical Applications

The Ultimate Pico RP2040 16MB Development Board can be used in many electronics and embedded development projects. It is suitable for IoT sensor nodes, robotics control systems, automation systems, display-based projects, USB HID devices, data logging applications, MicroPython learning, CircuitPython experiments, audio sample playback, and embedded product prototyping.

Its larger 16MB flash memory makes it especially useful for projects that require more storage than standard RP2040 boards. Developers can store scripts, libraries, configuration files, logs, and project assets directly on the board, making it a practical choice for advanced embedded applications.

Package Includes

1 × Ultimate Pico RP2040 16MB Development Board

Important Product Disclaimer

Please verify all technical specifications, pinouts, dimensions, flash size, and compatibility from the official datasheet or product documentation before using this product in final projects. Product labels, board layout, chip marking, flash memory brand, and minor hardware details may vary depending on batch or manufacturer supply. For critical applications, users should confirm the exact hardware version before purchase or usage.

Note

Images are for representation only. Actual product may differ slightly in appearance, color, component placement, or labeling depending on stock availability and manufacturing batch.
