MG90S Metal Gear Micro Servo Motor 9g

The MG90 is a metal digital steering gear. The digital steering gear is different in the circuit of the analog steering gear, and the smoothness is different.

Suitable for 450 helicopter swashplate steering gear, small robots, robots, ship models, car models and more.

Product model: MG90S

Product size: 22.8*12.2*28.5mm

Product weight: 15.3g

Working torque: 2KG/cm

Reaction speed: 0.11 sec / 60 deg (4.8 V)

Operating temperature: 0?C-55?C

Dead zone setting: 5 microseconds

Plug type: JR, FUTABA universal

Angle of rotation: up to 90 degrees

Servo type: digital servo

Operating voltage: 4.8V

Structural material: metal copper teeth, hollow cup motor, double ball bearing

Rudder line length: 25cm

Scope of application: Models such as small and medium-sized electric model aircraft.

The steering gear has three line definitions:

Dark gray: GND

Red: VCC4.8-7.2V

Orange line: pulse input
