250 Watt MY1016 ( DC Gear-Less Motor ) for E Bike
₹2,100.00 excl GST
Electric Bicycle permanent Magnet DC Motor MY1016
24 volt 250 watt output electric scooter and bike motor.
rated speed (rpm) :2650 +/- 5 %
rated current : ? 13.7A; current without load :0.7 – 1.4 A
rated torque :0.87 Nm
transmission :chain sprocket (11 teeth, pitch 1/4″=6,35 mm), exchangeable, fixation nut shaft diameter :10 mm (milled groove one-sided 1,5 mm)
Compare
Product Details:
Â
Â
| Minimum Order Quantity | 1 Unit |
| Speed | 2650 +- 5 %, 2000-6000 RPM |
| Voltage | <100 V,24 V |
| Power | 150-250 W |
| Commutation | Brush |
| Torque | 0.87 Nm |
| Current w / o Load | 0.7 – 1.4 A |
| Maximum / Rated Current | 13.7 A |
| Transmission | Chain Sprocket |
| # of Teeth | 11 |
| Sprocket Pitch | 6,35 mm i.e. 1/4 inch |
| Fixation Nut Shaft Diameter | 10 mm ( Milled Groove,One-Sided 1.5 mm ) |
Â
** The images shows are for representation only and actual product may slight differ in color and appearance.
