SIMA7670C GSM 4G LTE modem with RS232 Support and Foldable Antenna
₹1,350.00 excl GST
1 nos A7670C 4G LTE modem with RS232 Interface
SIM7670C 4G is a 4G LTE GSM module with SIm card Holder, SMA connector,DC Power,and an RS323 interface, Supports wireless Communications Modes of LTE – TDD/LTE-FDD/GSM/GPRS/EDGE
SIM7670C 4G board is build around the SIMCOM A7670C LTE Module and comes an RS232 interface,enables easy connection with the computer or laptop using a USB to serial connector or to the microcontroller using an RS232 to TTL converter.A-3 Pin header also exposes a 1.8V level UART interface for direct interfacing with microcontroller.communication with A7670C is done using AT commands
- Small size LTE Cat 1 module
- LGA form factor with abundant interfaces
- Suitable for LTE and GSM networks
- Abundant software functions: FOTA, LBS, SSL
- The form factor of A7670 series are compatible with the SIM7000/SIM7070 series
Please Note:- Image and color for refrence only. You may get green color board, Red color Color board or blue color board depending on stock availability.
Please Note: Images are for representation only. The actual Product may differ slightly in appearance.
Alex Tirkey (verified owner) –
Not compatible for any 4g sim
rohietkadaamh (store manager) –
Dear User,
This Modem is compatible with 4G simcards. We have tested with Airtel 4G and JIO 4G simcards. Recommended power supply using DC Jack is 12V 2A. If you are trying to communicate with Arduino or ESP32, You need an level shifter as this modem works on 1.8V ttl logic. If not use RS232 to TTL to communicate. So Please make sure you are using level shifter to communicate with the Modem.
