4-in-1 pH Sensor Module (pH, Light, Temperature, Water Level) TTL Interface for Arduino, Raspberry Pi, IoT Projects
₹399.00 excl GST
Package contains: 1 Nos 4-in-1 pH Sensor Module (pH, Light, Temperature, Water Level) TTL Interface for Arduino, Raspberry Pi, IoT Projects
🔍 Product Overview:
The Low Cost pH Sensor PCB Type with Level and LDR is a compact, multi-functional sensor module engineered to measure the pH value of liquids while simultaneously monitoring light intensity, temperature, and water level. Designed for Arduino, Raspberry Pi, ESP32, and other microcontroller platforms, it communicates via TTL UART using a 9600 baud rate, making it perfect for integration into IoT-based projects with Arduino, Raspberry Pi and Other controllers
📦 Key Features:
| Feature | Details |
|---|---|
| pH Measurement | Detects hydrogen ion activity to determine acidity or alkalinity (0–14 pH) |
| LDR Sensor | Monitors ambient light intensity using a light-dependent resistor |
| Temperature Sensor | Measures environmental temperature levels |
| Water Level Sensor | Detects water presence or level using a level detection circuit |
| TTL Communication | Standard TX/RX pins for serial communication at 9600 baud |
| Wide Compatibility | Works with Arduino, Raspberry Pi, AVR, STM32, and more |
🛠️ Connection Guide:
| Pin | Function |
|---|---|
| 5V | Power supply input (connect to 5V) |
| GND | Ground pin |
| TX | Connect to RX of TTL module |
| RX | Connect to TX of TTL module |
| D5 | pH sensor data output |
| D6 | Light sensor (LDR) data output |
| D7 | Temperature sensor data output |
📌 Applications:
-
🌾 Smart Farming & Agriculture – Soil water pH and environmental sensing
-
💧 Hydroponics & Aquaponics – Optimize water quality for plant growth
-
🧪 Water Quality Monitoring – pH and purity detection
-
🏭 Industrial Monitoring – Control and log fluid parameters in real-time
-
🌞 Light Intensity Adjustment – Automate lighting based on brightness level
Please Note : This is not an Industrial Grade pH Sensor and is fit for use with academic projects only. Support for this product is limited and proper handling is required.
